OphthalMed LLC

Illuminated Laser Probe 25g

This 8ft laser/illumination probe is indicated for Endo-Ocular laser photocoagulation treatments in order to provide coagulation and illumination during surgical interventions at laser operating wavelength of 500 to 1,100nm. The laser fiber is terminated from one side with a connector that attaches the fiber end to the laser source. It is terminated from one side with a connector that attaches the fiber end to the illumination machine. From the other side, it is terminated with a handpiece and a 25 gauge stainless steel tubing that holds the tip of the laser and illumination fibers. A flexible plastic jacket covers and protects the length of the fiber.


  • Ergonomic and non-slip handpiece design.
  • Different connectors that suit most laser source models available on the market.
  • Sterilized by Ethylene Oxide, single-use, latex-free.
  • Dia 0.51 mm (25ga), Length 2.4 m (8 ft)

    Illumination Connectors



    With the Nidek Laser Connector - Push-In*






    Alcon Accurus And Constellation Illumination Connector*

    Compatible with standard and high brightness illumination

    • B525204          Straight Tip
    • B565204          Curved Tip
    • B585204          Straight Extended Tip
    • B5A5204          Curved Extended Tip




    19 Gauge Illumination Connector

    • B525104          Straight Tip
    • B565104          Curved Tip
    • B585104          Straight Extended Tip
    • B5A5104          Curved Extended Tip


    Alcon Ocutome Illumination Connector*

    • B525304          Straight Tip
    • B565304          Curved Tip
    • B585304          Straight Extended Tip
    • B5A5304          Curved Extended Tip


    B&L Stellaris PC Illumination Connector*

    Compatible with high brightness illumination

    • B525504          Straight Tip
    • B565504          Curved Tip
    • B585504          Straight Extended Tip
    • B5A5504          Curved Extended Tip


    B&L / Storz Millenium Illumination Connector*

    • B525404          Straight Tip
    • B565404          Curved Tip
    • B585404          Straight Extended Tip
    • B5A5404          Curved Extended Tip

    *Trademarks are property of their respective owners
